HY12DSE/3 Diesel Generator Set

1. Generator Type：Silent 2 - Cylinder 4 - Stroke Diesel Generator Set
2. Engine Model：HY2V80DE
3. Phase Options：Single Phase (HY12DSE) 、Three Phase (HY12DSE/3)
4. Power Output：Rate Output 8.5 - 9.0 KW ；Max Output 9.5 - 10.0 KW
5. Engine Specifications：V - Type 2 - Cylinder 4 - Stroke Water Cooled Diesel Engine；Bore*Stroke 2×80×79 mm；Displacement 794 cc；Compression Ratio 20:01；Rated Power 12 - 14 KW (3000/3600 RPM)
6. Noise & Lubrication：Noise Level@7m 72 - 75 dB；Lube Type CF15W/40

 Send Email

 Inquiry

Product Description

Model No		HY12DSE		HY12DSE
Generator Set	Type	Silent 2 - Cylinder 4 - Stroke Diesel generator Set
	Rated Output:	8.5KW	9.0KW	8.5KW	9.0KW
	Max Output:	9.5KW	10.0KW	9.5KW	10.0KW
	Frequency:	50HZ	60HZ	50HZ	60HZ
	Phase No:	Single Phase		Three Phase
	Power Factor	CosΦ=1		CosΦ=0.8
	Noise Level@7m(dB)	72-75(dB)
	Excitation Mode	Brush(AVR)
	Starting Type	Electric Starter
Engine	Engine Model	HY2V80DE
	Engine Type	V - Type 2 - Cylinder 4 - Stroke Water Cooled Diesel Engine
	Bore*Stroke	2*80x79(mm)
	Displacement	794cc
	Rated Output:	12KW	14KW	12KW	14KW
	Rotation Speed:	3000 RPM	3600RPM	3000RPM	3600RPM
	Lube Type:	CF15W/40
	Compression Ratio	20:01
	Lube Capacity	1.5 - 3.3L
Packing	Net Weight	310KGS
	Gross Weight	335KGS
	Packing Dimensions(LxWxH)	1300x700x870mm
